The 13 semiregular convex polyhedra of Archimedes

Michael Lahanas

Αρχιμήδης : περί 13 ημικανονικών πολυέδρων

Griechische Mathematik. Archimedische Polyeder

There is an astonishing imagination in practical mathematics; and Archimedes had at least as much imagination as Homer, Voltaire

Archimedes of Syracuse knew that there exist 13 convex semiregular polyhedra. The so-called Platonic polyhedra are formed from identical regular polygons. For example the cube is formed by 6 squares and the tetrahedron using 4 isosceles (all three sides have the same length) triangles. Archimedes considered the problem how many polyhedra can be obtained if we use 2 or more combinations of regular polygons. For example the “small rhombicosidodecahedron” can be formed by 20 isosceles triangles, 30 squares and 12 regular pentagons. There are only 13 possible semiregular polyhedra. These are called also Archimedean solids. Archimedes work about the semiregular polyhedra is lost but there are references made by the mathematician Pappus.

Eureka, the Journal of the Archimedeans (Issue 53, 1994)

Pappus of Alexandria (Πάππος ο Αλεξανδρεύς) (about 290-350) AD is the author of Μαθηματική Συναγωγή, or shortly Συναγωγή (Synagoge) (Mathematical Collections), He describes the Archimedean solids in the 5th book of the Synagoge: See http://www.mcs.drexel.edu/~crorres/Archimedes/Solids/Pappus.html for parts of Pappus text)

Each face is a regular polygon, and around every vertex, the same polygons appear in the same sequence, for example, hexagon - hexagon – triangle in the truncated tetrahedron as can be seen from the picture at the start of the section. Two or more different polygons appear in each of the Archimedean solids, unlike the platonic solids which each contain only one single type of polygon.

Classification

The Five Truncations

Obtained from the corresponding Platonic Solids by dividing the edges into thirds and cutting off the vertices of these points.

truncated cube

(3, 8, 8)

truncated dodecahedron

(3, 10, 10)

truncated icosahedron

(5, 6, 6)

(geometry of the Carbon 60 molecule) or for less mathematical interested the shape of the soccer ball covered by pentagon and hexagons.

truncated octahedron

(4, 6, 6)

truncated tetrahedron

(3, 6, 6)

Snub Polyhedra

snub cube

or

snub cuboctahedron

(3, 3, 3, 3, 4)

snub dodecahedron

or

snub icosidodecahedron

(3, 3, 3, 3, 5)

Truncated-Quasiregular Polyhedra

great rhombicosidodecahedron

or

truncated icosidodecahedron

(4, 6, 10)

great rhombicuboctahedron

or

truncated cuboctahedron

(4, 6, 8)

Snub Polyhedra

snub cube

or

snub cuboctahedron

(3, 3, 3, 3, 4)

snub dodecahedron

or

snub icosidodecahedron

(3, 3, 3, 3, 5)

Quasi-regular Polyhedra

cuboctahedron

(3, 4, 3, 4)

icosidodecahedron

(3, 5, 3, 5)

For the notations such as (3, 4, 3, 4) see: Info Source

user action

applet reaction

dragging (left mouse button pressed)

rotating about an axis in the picture

releasing left mouse button while dragging

spinning about an axis in the picture

SHIFT key pressed plus vertical dragging

zooming

SHIFT key pressed plus horizontal dragging

rotating about an axis perpendicular to the picture

CONTROL key pressed plus vertical dragging

changing focal length

Polyhedron

Faces Number(Polygon)

Edges

Vertices

Truncated Tetrahedron

4(3), 4(6)

18

12

Truncated Cube

8(3), 6(8)

36

24

Cuboctahedron

8(3), 6(4)

24

12

Truncated Octahedron

8(6), 6(4)

36

24

Small Rhombicuboctahedron

8(3) ,18(4)

48

24

Great Rhombicuboctahedron

12(4), 8(6), 6(8)

72

48

Snub Cube

32(3), 6(4)

60

24

Truncated Dodecahedron

20(3), 12(10)

90

60

Icosidodecahedron

20(3), 12(5)

60

30

Truncated Icosahedron

12(5), 20(6)

90

60

Small Rhombicosidodecahedron

20(3), 30(4), 12(5)

120

60

Great Rhombicosidodecahedron

30(4), 20(6), 12(10)

180

120

Snub Dodecahedron

80(3), 12(5)

150

60


Kepler and Luca Pacioli after Archimedes were interested in these solids. Pacioli showed a truncated icosahedron in his book De Divina Proportione published around 1509. A regular dodecahedron is shown in the stamp one of the 5 regular Platonic solids.

For a more precise mathematical definition of these geometrical objects see Archimedean Polyhedra

References

Polyhedra, Peter R. Cromwell, Cambridge University Press, 1997. 451 pp. ISBN 0-521-55432

The Works of Archimedes: Translation and Commentary, Vol. 1 Reviel Netz, Cambridge University Press 2004

The Works of Archimedes , Thomas Little Heath, Dover Publications, Incorporated 2002
